4 In – 2 Out – XLR Bypass Control A/B Switch Box – Ground Lift

Original price was: 289.00 €.Current price is: 239.00 €.

4 XLR Inputs – 2 Balanced XLR Outputs
A/B Input Selector
Pin 1 Ground Lift (Both Inputs)

NO STEREO CROSSTALK!
NO STEREO IMAGE COLLAPSE!
DOES NOT AFFECT THE STEREO IMAGE!
DUAL STEREO BALANCED SIGNAL PATH!
FULLY BALANCED FROM INPUT TO OUTPUT!
NO RELATION/CONNECTION BETWEEN L/R SIDES!

Designed for RME ADI-2 DAC FS • Pro-Ject • Cayin HA-6A MK2 • Rega Osiris

Can’t find the right controller or switcher? Tell me what you need—I’ll build it!

Custom Passive XLR Audio Routing

4 XLR Inputs, 2 XLR Outputs, Balanced Signal Path, Input A/B Select Switch, and Pin 1 Ground Lift on Both Inputs for Noise-Free Audio Routing -System for RME, FiiO, Pro-Ject, Cayin & Rega

A fully passive, relay-free audio routing system designed for maximum signal integrity and flexibility. The unit allows seamless switching between multiple balanced audio sources and two independent signal paths: a direct full-balanced bypass path and an optional tube-buffer path.

Connected Equipment

  • RME ADI-2 DAC FS
  • FiiO DAC
  • Pro-Ject Turntable (via balanced phono preamplifier)
  • Cayin HA-6A MK2 (tube stage)
  • Rega Osiris Integrated Amplifier

Signal Flow – see switch diagram – designed by customer – Zack Benjamin

  • Selects between:
    • Tube Path: Signal processed through the Cayin HA-6A MK2.
    • Direct Bypass Path: Pure passive balanced connection with no active circuitry.
  • Sends the selected signal to the Rega Osiris balanced XLR input.
  • Ground Lift Switch – uDisconnects Pin 1 XLR Ground)

Design Features

  • 100% passive audio routing
  • No power supply required
  • No relays or active electronics in the signal path
  • Gold-plated switch contacts
  • Full balanced XLR signal integrity maintained on the bypass path
  • Excellent common-mode noise rejection throughout the balanced signal chain
  • Minimal insertion loss
  • Transparent signal routing with no coloration in bypass mode
  • Instant A/B comparison between direct and tube-buffered playback

Intended Use

Designed for high-end audio systems where multiple balanced sources must be routed through either a pure direct path or a selectable tube stage while maintaining the shortest possible signal path and maximum audio fidelity.

You can get as many channels and options as you want, so let’s build your gear!

Build time: 10 Working Weekdays after cleared payment

Do not find your controller or switcher? Tell me what you need and I build for you!
