4 x Stereo DSUB Swap Sequence Insert Bypass Studio Mastering switch-TRS or XLR I/O (select) switcher box

695.00 715.00

True Analog AB/BA Flip-Swap Stereo Sequence Switcher switcher box – Analog Relay Circuit Switching Device – QUAD Stereo Balanced Studio Mastering Insert Bypass Switch Box for Outboards

ANY CONNECTOR TYPE CAN BE ORDERED IN ANY SEQUENCE AND VARIATION

SELECT ALL OPTIONS!

The order of the outboards can be swapped AB / or BA or any other variation (let me know)

Specs: Insert Bypass Studio Mastering switch
1U Standard Rack Unit
2 in TRS or XLR Balanced L/R (select)
2 out TRS or XLR Balanced L/R (select)
4 x Stereo Insert Send via DSUB Balanced ABCD
4 x Stereo Insert Return via DSUB Balanced ABCD
4 x SND/RET Bypass Switches total 8 stereo switches ABCD (solid state passive)
Swap Sequence Switching: AB/BA-BC/CB-CD/DC
Select LED color for swap / power
Custom Name Engraving: Let me know

Frequency Response (Passive Section) +0, -0.1dB from 10Hz to 30kHz
Maximum level > +28dBu • Noise floor < -94.5dBu 22Hz-22kHz bandwidth
THD+N < 0.004% • IMD < 0.004%
Crosstalk rejection (Passive Section) > 110dB

Audio Studio insert bypass switching device switch box signal select distribution splitter swap flip relay patchbay.

Do not find your desired gear?  Ask to build Yours!

You can get as many channels and options as you want, so let’s build your gear!

Build time: 15 Working Weekdays after cleared payment

AB/BA Flip-Swap Stereo Mastering Studio Relay Circuit Switching switcher box Device Patchbay Quad 4x Stereo ABCD Insert with 4x 2 (eight) Send Return Bypass Switch sets for outboard effect processors

IN-OUT CONNECTION TYPE

TRS IN – TRS OUT, XLR IN – XLR OUT, XLR IN – TRS OUT, TRS IN – XLR OUT

SWAP SEQUENCE ORDER

AB/BA, BC/CB, CD/DC, OTHER – let me know

POWER LED COLOR

WHITE, RED, GREEN, YELLOW, BLUE

SWAP LED COLOR

WHITE, RED, GREEN, YELLOW, BLUE

CUSTOM NAME?

YES (let me know), NO THANKS

BUILD TIME

15 WORKING DAYS
