4-Channel XLR Summing Mixer with Volume Control – Mute & Mono Switch

Pro Tip: Push the instruments into the summing mixer at a higher level until you start hearing a subtle harmonic distortion. This will add warmth, depth, and better separation to your mix, giving it a more professional, polished sound—just like a finished record. The headroom provides a safe place for transients, ensuring clarity and punch in your mix.

Features:

• Base Summing Circuit Reduction: -6dB
  Optional attenuation levels: -6dB, -10dB, -15dB, -20dB, or -25dB (let me know)

• Inputs: 4 x Balanced XLR

• Outputs: 2 x Balanced XLR

• Controls:
  – 4 x Input Mute Switches
  – 4 x Mono Switches read more about Mono option…
  – 4 x Input Attenuators (Linear or Step Precision)
  Option to upgrade to 21-Step Precision Attenuators via dropdown menu (reverse anti-clockwise vise operation)

• Attenuator Range: 0 to -20dB (Balanced)
  This attenuation is in addition to the base reduction. For example: -6dB base + 0 to -20dB via the attenuator = total adjustable attenuation.

• Select your Insterface sound card: UAD Apollo | Focusrite | Motu | M-Audio | Presonus | Behringer | Roland | Tascam | RME | SSL | Apogee | OTHER
• Custom Name Engraving?
• Build time: 8 -10 business/working weekdays (estimated)

How to connect a summing mixer to the DAW? YOUTUBE

4-Channel XLR Summing Mixer with Volume Control, Mute & Mono Switches

Take full control of your analog summing with this compact and powerful 4-channel XLR summing mixer. Designed for balanced audio setups, it features 4 XLR inputs and 2 XLR outputs, giving you clean, transparent summing with professional flexibility.

Each channel includes a dedicated mute switch, mono switch, and input attenuator—with a choice between smooth linear control or a 21-step precision upgrade for detailed level adjustments.

The mixer includes a base summing circuit attenuation of -6dB, with optional reductions down to -25dB. Combined with individual 0 to -20dB input attenuators, you get fine-tuned control over every signal in your mix.

Summing Mixer with Volume Control Perfect for studios, live setups, or any balanced audio application where precision and simplicity meet.
