24-Ch Analog Studio Direct Out Breakout Box – DSUB ↔ TRS Bi-Directional Patchbay

Professional analog breakout box designed for clean and reliable signal routing in studio environments. The unit provides 24 fully balanced channels via DB25 (DSUB) connectors to TRS balanced jacks, making it ideal for interfacing audio interfaces, mixing consoles, and patchbays.

Key Features

• 24 fully balanced analog I/O

• Bi-directional operation – works in both directions (DSUB ↔ TRS)

• 3 independent 8-channel sections for flexible routing

• High-quality connectors for reliable studio integration

• Ideal for studio direct outs, converters, mixers, and patchbay systems

Configuration

• Section A: 8 × DSUB → 8 × TRS Balanced

• Section B: 8 × DSUB → 8 × TRS Balanced

• Section C: 8 × DSUB → 8 × TRS Balanced

Total:

• 24 channels balanced analog signal routing

• 24 DSUB (DB25 standard) ↔ 24 TRS balanced connections

Perfect solution for studios needing a compact, organized way to break out DB25 connections into standard TRS balanced lines, while maintaining professional signal integrity.

Do not find your studio gear? Tell me your DAW Interface Type! Ask to build Yours!

ORDER HERE

The VM24x24 Breakout Box Patchbay is a 1U rackmount breakout/patchbay with four 25-pin female DSUB connectors, each internally wired to 8 female 1/4″ TRS jacks. This setup provides a total of 24 TRS channels, which can be used for either balanced or unbalanced signals as needed. Its bi-directional design allows flexible routing as both sends and returns, with a fully transparent stereo balanced signal path for high-quality audio transmission. Rackmount DSUB to TRS Breakout Box Stereo Balanced Studio Patchbay, RME DTOX, Behringer ULTRALINK MS8000, ART P16
